| Nominal Capacity | 1500mAh |
| Battery discharged at continuous current 1mA until voltage reaches cut-off voltage 2.0V at ambient temperature 23±2℃ |
| Nominal Voltage | 3.0 V |
| Maximum Continuous Current | 600mA |
| Battery with minimum 50% rated capacity discharged at ambient temperature 23±2℃ |
| Maximum Pulse Discharge Current | 1000mA |
| Battery with minimum 50% rated capacity discharged at max pulse for 3 seconds after 27seconds break. Ambient temperature 23±2℃ |
| Storage Condition | Temperature ≤ 30℃ Humidity ≤ 75%RH |
| Operating Temperature | -40℃ to +60℃ |
| Battery Dimension | See drawing on pag |
| Max Weight | 13.0g |
| Self-discharge Rate | 2% |
| Max self-discharged rate at ambient temperature 23±2℃ |
| Shelf Life | 10 years |
| Ambient temperature 23±2℃ |
1. Li-MnO2 Soft Battery 1500mAh CP702440 Battery Characteristic
The nominal voltage of single cell up to 3.0V
We provide the specific energy density up to 346Wh/kg, 50% higher than the steel-shelled lithium cell of the same weight
- Wide Operating Temperature Range
Battery working temperature range from -40℃ to +70℃
The battery self-discharge less than 2% per year at room temperature
2. Li-MnO2 Soft Battery 1500mAh CP702440 Main Applications
Cardiac pacemaker, respirator, oxygenator, inspection devices, monitoring devices, infusion pump, etc.
Smoke detectors, security alarms, seismometers, locking system, monitoring system, etc.
RFID products, road toll transponder, IC cards, etc.
3. Use Warning
- Do not throw battery into open fire. This can cause violent rupture due to the heat.
- Do not throw the battery into water. This can cause explosion.
- Do not charge primary batteries. This can cause gas leakage and will lead to violent rupture and/or fire.
- Battery compartment should provide sufficient space for battery to expand in case of abuse.
- Battery disposal method should be in accordance with local and state regulations.
4.Company Advantages
- Quality management system of HCB is conformity with GB/T19001-2008/ISO9001:2008 standard;
- HCB Environment Management System meets the standard GB/T24001-2004/ISO14001:2004;
- The battery can pass drop test if you need;
- Report for safe transport of goods can be provided with you if needed;
- We can provide you with the CE certificate if you need;
- Rosh Standard is workable for HCB Battery;
- UL Standard is workable for HCB Battery.
